Product Design Shorts: Trick Out Your Car, Fly Hands Free, and Lift 20-Ton Trucks
Written By: Cat McClintock

What’s up in the world of product design? Here are stories from the past month we think you’ll like:

Trick out your car with this product designed to add flair

At PTC’s LiveWorx event recently, Stratasys showed off an interesting use for additive manufacturing—custom skins for your car. From Korea’s Daihatsu, these decorative panels attach to a vehicle, giving it a one-of-a-kind look. And because they’re 3D printed (i.e., no tooling needed), they can be relatively inexpensive.

 Product design that allows you to add texture to front end of car

The unique piece in the image above is composed of acrylic-styrene-acrylonitrile (ASA) polymers, and printed using fused deposition modeling (FDM). Stratasys reps said engineers liked ASA for this application because it offers a higher UV tolerance than other plastics.

Panel has been printed, sanded, and painted

Panel on display at LiveWorx. This piece was printed, sanded, and painted.


Fly hands-free

As summer marches on, we’re currently reading Bill Bryson’s One Summer: America, 1927. The book, a couple years old, provides a glimpse into the U.S. (and the world) during the tail-end of the 1920s. For instance? Non-stop transatlantic plane flights. They were unheard of. They were uncomfortable. And they injured, maimed, and killed numerous pilots trying to master the achievement. What’s this have to do with product design? Nothing really, just that it makes Sikorsky’s latest demonstration of a 30-mile flight with an operator planning and executing every phase of its mission using a tablet seem so, well, amazing. Talk about being thrust back in the present. Here’s the video that shows the pilot maneuvering the aircraft, Again, with a tablet.

Lift the big trucks

Say your customer needs to get under a 20-ton fire truck to, I don’t know, change the oil. You can’t drive that thing into the local Jiffy Lube. You need a special lift to get under there. That’s the business Rotary Lift is in. Check out their most recent product release:

Rotary Lift's all-new V-REX vertical rise, drive-on platform scissor lift raises the biggest, baddest vehicles more than 77 inches in the air without a whimper.”

When was the last time you designed a product described as the “biggest and the baddest”? OK, sure, the marketing folks had a hand in this yet still, it’s a nice goal to have. And the V-REX?  It features four-bar engineered rotational linkages that transfer shear forces to the foundation, optimizing lift efficiency and decreasing installation costs. Because the legs feature rotational hinge links that rotate and pivot instead of sliding, they are more efficient and longer lasting. That’s pretty big.

Mobile lift designed to raise 20-ton trucks

Get designing

If you’re looking to design inspirational products, make sure you’re using the product design software that’s best for your needs. Find out what you need to know by taking our 3-day email course. As you begin your research, use this information to walk you through each step of the CAD software buying process.

Free three-day email course
