Geometric Dimensioning and Tolerancing (GD&T) is a symbolic language used to communicate design specifications. GD&T can speed up processes and reduce errors.
A 3D model annotated with GD&T information.
You’ll have fewer prototypes and scrap parts because you’ve told manufacturing just how much a part can deviate from the design before it just won’t work anymore.
However, just like any method of communication, GD&T is only effective if everyone is speaking the same language—or using the same set of standards. It doesn’t work if even a few people aren’t using it correctly.
GD&T symbols—Do you know what they mean?
Creo takes the guess work out of GD&T. Your organization will communicate with a universal language—a common set of standards. For example, ASME Y14.5-2009.
In Creo, tolerances are automatically checked for compliance with ASME standards. Take a look:
Here’s how to check an annotation for ASME compliance:
If the tolerance/symbol violates ASME standards, you’ll see a warning message. Like this one:
Are you a PTC Support customer? You can learn more about how to create a geometric tolerance in Creo Parametric from this Support Knowledge Base article. These articles are one of the many benefits available to PTC Support customers.
