Did you get a chance to join PTC University and Creo Curriculum Manager, Matt Huybrecht for Session 3: Managing Design Intent and Editing References in our Going Live with PTC University webinar series?
If not, we’ve got you covered. Check out these five key takeaways from Session 3 and make sure to register and attend the remainder of this FREE eight-part webinar series. We’ll meet you there!
Design intent is the way you create models so that they behave in a predictable manner when they are modified. It’s essential to give forethought into how your designs are constructed in Creo and consider the product’s entire lifecycle. Doing so will allow you to create robust models and enable you to edit references to features thereby increasing your productivity.
Because internal sketches are embedded in the feature they define, you always know where to find them. External sketches are separate features that can be renamed and reordered in the same manner as other features. Because internal sketches are not features, they do not add to the total number of features in a model. Creating a separate external sketch for every sketched feature in your model can dramatically increase the number of features in a model, but gives you more flexibility and allows you to use the same sketch for multiple features. In models containing hundreds or even thousands of features, external sketches can dramatically increase the total feature count in a model. Again, this is something you want to consider when selecting the type of sketch to use.
Design intent is captured in features by specifying the correct feature, its references, and its options. As a result, you must carefully consider which feature options to specify to properly capture your design intent. You can always modify the feature's design intent, but it is easiest to do when you have planned for future modifications.
You can use Edit References to view and highlight existing feature references and specify new references as desired. When you edit the references of a feature, the system highlights all of the parent references used to create the feature. For each reference you can maintain the same reference, or you can select or create a new reference.
When a change is made to a parent feature, it automatically updates any children. This is beneficial functionality and demonstrates the power of Creo Parametric. However, within Sketcher if you delete an entity that has children, it may cause the child to no longer be able to find its parent reference, causing a failure. Instead, when modifying Sketcher geometry, create the new Sketcher entity first, then use the Replace operation to transfer the child references from the old entity to the entity. The system automatically removes the entity you wanted to delete, but because the child references were transferred to the new entity you reduce the chances of downstream child failures.
